ANSI Hardware Installation Manual Installing a 7360 ISAM FX-12 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 155
DRAFT
9.2.3 Recommended tools
The following tools are recommended:
• screwdrivers
• protective gloves
Procedure 29 To mount the 7360 ISAM FX-12 shelf vertically in a 19 in. rack
Use this procedure to mount a 7360 ISAM FX-12 shelf vertically in a seismic 19 in. rack.
1 Unpack and visually inspect the shelf for physical damage.
2 If anything is missing or damaged, notify the transportation carrier and Nokia immediately.
Photograph all the damaged equipment. Keep all the inspection and packing documents as
a reference.
3 Put on the antistatic wrist strap and connect it to a grounding point.
4 Verify the 7360 ISAM FX-12 shelf mounting locations on the rack; see Figure 71.
5 Orient the 7360 ISAM FX-12 shelf vertically with the fan unit located at the bottom of the shelf,
and align the shelf unit with the left and right rack mounting holes.
6 Mount the 7360 ISAM FX-12 shelf within the rack, using 12 mm pan head screws and
alternating between mounting holes on the right and left sides of the shelf, until all ten screws
have been used and the shelf is securely in place.
Warning — Possibility of equipment damage.
Do not install damaged equipment, as it can adversely affect other
equipment.
