Table 22 External Alarm Cable
Table 24 describes the CO external alarm pinning for the 7360 ISAM FX-16 shelf.
Table 23 CO external alarm pinning for 7360 ISAM FX-16
Signal Name Type Connectors Description
Subrack side
pin number
CO side cable
color
MISC1_ALA_A 1 1 Blue Miscellaneous Alarm 1 (A wire)
MISC1_ALA_B 1 9 White Miscellaneous Alarm 1 (B wire)
MISC2_ALA_A 1 2 Orange Miscellaneous Alarm 2 (A wire)
MISC2_ALA_B 1 10 White Miscellaneous Alarm 2 (B wire)
MISC3_ALA_A 1 3 Green Miscellaneous Alarm 3 (A wire)
MISC3_ALA_B 1 11 White Miscellaneous Alarm 3 (B wire)
MISC4_ALA_A 1 4 Brown Miscellaneous Alarm 4 (A wire)
MISC4_ALA_B 1 12 White Miscellaneous Alarm 4 (B wire)
MISC5_ALA_A 1 5 Grey Miscellaneous Alarm 5 (A wire)
MISC5_ALA_B 1 13 White Miscellaneous Alarm 5 (B wire)
MISC1_OUT_A 0 6 Blue Miscellaneous Alarm Output 1 (A wire)
MISC1_OUT_B 0 14 Red Miscellaneous Alarm Output 1 (B wire)
MISC2_OUT_A 0 7 Orange Miscellaneous Alarm Output 2 (A wire)
MISC2_OUT_B 0 15 Red Miscellaneous Alarm Output 2 (B wire)
8 - Not connected
FG 16 - Frame ground
FG 17 - Frame ground
Signal name Type Pin number Color Description
EXT_ALM0_00 Input 1 White/tan External alarm input 1 (A terminal)
EXT_ALM0_01 26 Tan/white External alarm input 1 (B terminal)
EXT_ALM0_10 Input 2 White/brown External alarm input 2 (A terminal)
EXT_ALM0_11 27 Brown/white External alarm input 2 (B terminal)
EXT_ALM0_20 Input 3 White/pink External alarm input 3 (A terminal)
EXT_ALM0_21 28 Pink/white External alarm input 3 (B terminal)
EXT_ALM0_30 Input 4 White/orange External alarm input 4 (A terminal)
EXT_ALM0_31 29 Orange/white External alarm input 4 (B terminal)
