Overview
44
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Figure 5 Horizontal mount position for 7360 ISAM FX-8 in a 19 in. rack
Energy Hazzard
22736
TOD/IHZ
FAN
NTA
NTIO NTB 01 02 03 04 05 06 07 08
7360 ISAM FX-8
Energy Hazard
Critical
Alarms
ACO
BAT A
Remote Craft
BITS
External Alarms
Major
Minor
BAT B
7360 ISAM FX-8
B-40A
A-40A
NTA GND NTB
18.312
17.750
35 RU
8 RU
