Installing a 7360 ISAM FX-8 shelf

246

ANSI Hardware Installation Manual

3HH-12893-AAAA-TCZZA Issue: 09

DRAFT

7 Mount the 7360 ISAM FX-8 shelf with 12-24 × 1/2 in. (12.7 mm) screws to the left mounting

plate on the rack, then to the right mounting plate on the rack securely; see Figure 129.

Figure 129 Horizontal mounting installation for 7360 ISAM FX-8 in a 23 in.

rack

8 STOP. This procedure is complete.

Note — See Chapter 14 “7360 ISAM FX-8 shelf cabling” for

7360 ISAM FX-8 shelf cabling information.

Left shelf bracket

Right shelf bracket

22745
