ANSI Hardware Installation Manual 7360 ISAM FX-8 shelf cabling
Issue: 09 3HH-12893-AAAA-TCZZA 277
DRAFT
14.12.1 VL cable
The VL cables must not be routed where they may be exposed to high voltage such
as lightning strikes.
While no particular arrangement of VL cables between SLV LTs and VL ports on the
centralized vector processor card is required, it may be desirable to maintain a
particular connection arrangement of these cables.In those circumstances, both
ends of all cables may be labeled before installation so that each cable is uniquely
identified. Examples of such identification include operator-provided colored zip ties
and colored or write-on labels.
14.12.2 Prerequisites
The following tools are required:
• antistatic wrist strap
The following parts are required:
• cable ties or lacing cord
• QSFP+ 1m cable (3FE 68462 AA)
Caution — When VL cables need to be disconnected, only do
so by pulling the release ring tab. Do not pull on the cable itself
or on the QSFP+ modules pre-installed at each end.
