Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Installing cards in the 7360 ISAM WM shelf
Issue: 09 3HH-12893-AAAA-TCZZA 419
DRAFT
23 Installing cards in the
7360 ISAM WM shelf
23.1 Overview
23.2 Shelf areas and slot positions
23.3 Dummy front panels
23.4 Recommended tools
23.5 Guideline for card installation
23.6 Installation procedures
23.1 Overview
This chapter provides the procedures to install field-replaceable units (FRUs) in a
7360 ISAM WM shelf.
23.2 Shelf areas and slot positions
Figure 244 shows the line card, power card, and controller card slot positions in a
7360 ISAM WM shelf.
Note — For an overview of the supported cards, see the
7360 ISAM FX Product Information Guide.
