Nokia 7360 Intelligent Services Access Manager FX Series User Manual

Installing cards in the 7360 ISAM FX-8 shelf
292
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Figure 157 Laser classification label
Procedure 61 To install NTIO cards
Each shelf containing one or two redundant NT boards can have an NT I/O applique. The NT I/O
applique is a single board which is installed in the NT I/O slot between the two NT slots of the FX-
8 shelf.
1 Remove the NT I/O board from its ESD protective bag. Make sure to wear the antistatic wrist
strap.
2 Insert the NTIO board in the NTIO slot; see Figure 158.
Figure 158 NTIO slot
CLASS 1 LASER PRODUCT
18256
TOD/IHZ
24502
FAN
NTA
NTIO NTB 01 02 03 04 05 06 07 08
7360 ISAM FX-8
Energy Hazard
Critical
Alarms
ACO
BAT A
Remote Craft
BITS
External Alarms
Major
Minor
BAT B
7360 ISAM FX-8
B-40A
A-40A
NTA GND NTB
NT B
NT A
NTIO
