7360 ISAM FX-16 shelf cabling
114
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
6.9 Remote craft port connector
The 7360 ISAM FX-16 requires a DB-9 female connector for the remote craft port
connection.
When the remote craft port is provisioned as a DCE port, meaning it connects to a
remote modem, the straight through DB-9 female connector cable is required. When
the remote craft port is provisioned as a DTE port, meaning it connects to a
computer, a DB-9 null-modem cable is required to invert the TX and RX signals. A
commercially available DB-9 male adapter cable can be used with the DB-9 female
connector cable to enable the use of standard cables.
Figure 43 also shows the remote craft port connection located on the bottom left side
of the 7360 ISAM FX-16.
For a description of the remote craft port connection pinning, see Appendix 25.
6.10 Combo cable connector
This section describes the cabling procedure for the interconnection cabling between
the voice LT card and the splitter card in an 7360 ISAM FX-16, in case of Combo
configuration.
6.10.1 Cable type
The required cable is an MDF cable with two CHAMP100 connectors; see Figure 44.
Note — Nokia supports the use of a DB-9 female connector
cable for the remote craft port connection to avoid potential
damage due to exposed pins on the typically used DB-9 male
connector.
