ANSI Hardware Installation Manual 7360 ISAM FX-16 shelf cabling
Issue: 09 3HH-12893-AAAA-TCZZA 107
DRAFT
Figure 38 Safety cover label
6.5.3 Power cables
This section provides information about the types of power connection cables, cable
routing, and a procedure for connecting the power cables on the 7360 ISAM FX-16.
6.5.3.1 Power cable type
The 7360 ISAM FX-16 requires the use of a 2 AWG power cable.
6.5.3.2 Power cable routing and connection
The power cables are routed through the left side of the rack and can then be routed
to the power distribution terminal block located on the bottom of the shelf; see
Figure 39.
CAUTION: BEFORE REMOVING TERMINAL COVER,
DISCONNECT BOTH “A” AND “B” POWER SOURCES
CAUTION: TORQUE NUTS TO 65-LBS MAX
22371
Note 1 — The color of the power cables must be according to
local installation practices.
Note 2 — Nokia recommends the following crimp lugs and
tooling for −48 Vdc input and return:
• input power lug: 2 AWG, 90C, Burndy YAZ2C-2TC14 or
equivalent
• 2 AWG 1/4 - 5/8 dual-hole copper lug, long barrel, peep,
uses Burndy Die Code 10. See Burndy catalog for additional
tool options.
• input power lug: 2 AWG, 90C, Thomas and Betts
54855BEPH or equivalent
• 2 AWG 1/4 - 5/8 dual-hole copper lug, long barrel, peep,
uses Thomas and Betts Die Code 33. See Thomas and
Betts catalog for additional tool options.
Note 3 — All required washers and nuts are included with the
shelf.
