ANSI Hardware Installation Manual Overview

Issue: 09 3HH-12893-AAAA-TCZZA 47

DRAFT

Figure 8 Horizontal mount position for 7360 ISAM FX-4 in a 23 in. rack

22738

22.313

21.500

38 RU

5 RU

FAN

NTA NTIO NTB 01 02 03 04

7360 ISAM FX-4

TOD/IHZ

Critical Alarms

FUSE

BAT A

Remote CraftBITSExternal Alarms

NTA GND NTB

Major

ACO

Minor

BAT B

N594

7360 ISAM FX-4
