Figure 40 Mounting of power cable shoes and safety cover on 7360 ISAM FX-16
3 Remove the nuts from the power terminals.
4 Guide the power cables through the cable guide and connect them to the power terminals as
follows:
• first connect the BATRET cables RET A and RET B
• then connect the battery cables BAT A and BAT B
22192
Energy Hazard
ALM
01 02 03 04 05 06 07 08 NTA
NTIO NTB 09 10 11 12 13 14 15 16
7360 ISAM FX-16
N594
R
T
H
A
E
B
O
N
D
I
N
G
P
O
I
N
T
ESD
ON
OFF
A/70 FOR LT
ON
OFF
B/70 FOR LT
-48V 70A
Energy Hazard
BAT A
BAT B
ACO
CRITICAL
MAJOR
MINOR
BITS INTERFACE
TIME OF DAY
1 Hz-PULSE
NT-A NT-B
RING
TIP
FRAME GND
CO ALARMS
CRAFT PORT
TB1-2 BA
T
R
TN A
TB1-
3 B
AT
R
TN B
TB1-1 -4
8V B
A
T A
TB1-4 -4
8V B
A
T B
CAUTION: BEFORE REMOVING TERMINAL COVER,
DISCONNECT BOTH “A” AND “B” POWER SOURCES
CAUTION: TORQUE NUTS TO 65 IN-LBS MAX
Danger — If the following sequence is not followed exactly, there can
be a possible fire hazard.
