7360 ISAM FX-12 shelf cabling

184

ANSI Hardware Installation Manual

3HH-12893-AAAA-TCZZA Issue: 09

DRAFT

Figure 88 MDF cable for 48-line cards

10.11.2 Prerequisites

The following tools are required:

• MDF (LINE/POTS) cables as provided by Nokia

• an antistatic wrist strap

• tie-wraps

• lacing cord for tying up and/or bundling cables

Note — See Appendix 25 for the pinning of the CHAMP100

connectors.

Solder side

125

76 100

No3455
