ANSI Hardware Installation Manual Installing a 7360 ISAM FX-8 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 255
DRAFT
7 In case of replacement, remove the installed fan unit:
i Loosen the captive screw of the fan cover and remove the cover; see Figure 135.
Figure 135 Fan installation for 7360 ISAM FX-8
ii Pull the fan unit out of the fan area by the handles.
iii If a fan filter was installed, remove the fan filter.
8 If the system is active, keep in mind the maximum time (5 minutes) fans are allowed to be
out of operation (see Danger warning about the risk of fire).
Danger — When the fan unit is extracted, the fans will still be rotating.
Do not touch the fans, because this may cause bodily harm.
Caution — Be careful when removing the fan filter to ensure that dust
will not get into the card cage area and onto the card components to
prevent possible damage to the other equipment.
