Installing a 7360 ISAM FX-8 shelf
254
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Procedure 52 To install or replace a fan unit
Use the following procedure to install or replace a fan unit.
1 Unpack and inspect the fan unit visually for physical damage.
2 If anything is missing or damaged, notify the transportation carrier and Nokia immediately.
Photograph all the damaged equipment. Keep all the inspection and packing documents as
a reference.
3 Put on the antistatic wrist strap and connect it to a grounding point.
4 Verify if the fan unit type is correct for the rack configuration. See Table 10.
5 Verify the mounting position of the fan unit; see Figure 128.
6 Remove the fan unit from its shipping packaging and inspect it for damage. If damaged, do
not mount the fan unit but notify the transportation carrier and Nokia immediately.
Warning — Possibility of equipment damage.
Do not install damaged equipment, as it can adversely affect other
equipment.
