ANSI Hardware Installation Manual Installing a 7360 ISAM FX-8 shelf

Issue: 09 3HH-12893-AAAA-TCZZA 241

DRAFT

Figure 126 Horizontal mounting configuration in a 23 in. rack for

7360 ISAM FX-8

Table 11 describes the vertical rack mounting configuration for a 7360 ISAM FX-8

shelf in a 23 in. rack. Figure 127 shows the vertical rack mounting configuration.

Energy Hazzard

TOD/IHZ

FAN

NTA

NTIO NTB 01 02 03 04 05 06 07 08

7360 ISAM FX-8

Energy Hazard

Critical

Alarms

ACO

BAT A

Remote Craft

BITS

External Alarms

Major

Minor

BAT B

7360 ISAM FX-8

B-40A

A-40A

NTA GND NTB

22734

22.313

21.500

35 RU

8 RU
