ANSI Hardware Installation Manual Fiber optic cable management in the
7360 ISAM WM shelf
Issue: 09 3HH-12893-AAAA-TCZZA 435
DRAFT
Figure 257 Fiber routing with a fiber management guide for the
7360 ISAM WM
Procedure 100 To mount the fiber management guide
Use the following procedure to mount the fiber management guide onto the 7360 ISAM WM shelf.
1 Align the pre-assembled fiber management bracket and fiber guiding elements with the finger
guides located on the top of the shelf; see Figure 258.
Figure 258 Alignment of 7360 ISAM WM fiber management guide
25370
PWR
AS
ALM
2
4
6
1
3
5
PWR
AS
ALM
2
4
6
1
3
5
PWR
AS
ALM
2
4
6
1
3
5
PWR
AS
ALM
2
4
6
1
3
5
PWR
AS
ALM
2
4
6
1
3
5
PWR
AS
ALM
2
4
6
1
3
5
Notch
Finger guide
22203
