Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Installing cards in the 7360 ISAM FX-12 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 193
DRAFT
11 Installing cards in the 7360 ISAM
FX-12 shelf
11.1 Overview
11.2 Shelf areas and slot positions
11.3 Dummy front panels
11.4 Recommended tools
11.5 Guideline for card installation
11.6 Installation procedures
11.1 Overview
This chapter provides the procedures to install field-replaceable units (FRUs) in a
7360 ISAM FX-12 shelf.
11.2 Shelf areas and slot positions
Figure 94 shows the LT and NT card slot positions in a 7360 ISAM FX-12 shelf.
Note — For an overview of the supported cards, see the
7360 ISAM FX Product Information Guide.
