Nokia 7360 Intelligent Services Access Manager FX Series User Manual

Installing cards in the 7360 ISAM FX-8 shelf
298
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Figure 162 Ejector handles for LT cards
Figure 163 Ejector handles for NT cards
5 Remove the card from its slot and place it in an ESD protective bag.
6 STOP. This procedure is complete.
Procedure 65 To change the NGFC-H card
Use the following procedure to change the NGFC-H card on the 7360 ISAM FX-8 shelf.
1 Before disconnecting the power cable, ensure that power to the cables has been
disconnected and the circuit breakers are switched to the off position.
2 Remove the safety cover and power cable connectors (loosen and remove the screws); see
Figure 164.
Withdrawl
Guiding plate
25830
33.77 in.
85.8 cm
22375
Warning — If the following steps to disconnect the power cables are
not followed exactly, there can be a possible fire hazard.
