Page #38 background imageLoading...
Page #38 background image
Overview
38
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
To meet heat dissipation requirements, equipment arrangements in racks higher
than 7 ft are identical to those for a 7 ft rack. Depending on company operating
practices, customer-provided ancillary equipment can be mounted above the 7-ft
level in these racks.
Customers can provide their own equipment racks and order 7360 ISAM FX
equipment from Nokia. The customer-provided rack must meet or exceed the rack
specifications as specified in the relevant unit data sheet.
Table 5 describes the 7360 ISAM FX rack configurations showing the EIA standard
required rack space, mounting options, and rack layout supported for each
7360 ISAM FX shelf (depending on company operational practices).
See the 7360 ISAM FX Safety Manual for shelf power consumption information.
Table 5 Supported rack configurations for 7360 ISAM FX
Note — The supported 7360 ISAM FX vertical mount rack
configurations for FX-16, FX-8, and FX-4 meet NEBS
compliance specifications.
Shelf Rack configuration (7 ft
rack)
EIA rack space Mounting
7360 ISAM FX-16
(1)
Up to 2 shelves per rack 17 Ru high per shelf unit Vertical mount in a 23 in. rack with 21.5 in.
opening
7360 ISAM FX-12 Up to 2 shelves per rack 15.5 Ru high per shelf unit Vertical mount in a seismic 19 in. rack with 17.5 in.
opening
7360 ISAM FX-8
(3)
Up to 2 shelves per rack 16 Ru high per shelf unit Vertical mount in an EIA standard 19 in. rack with
17.75 in. opening
Vertical mount in a seismic rack with 17.5 in.
opening
Vertical mount in a 23 in. rack with 21.5 in.
opening
7360 ISAM FX-8
(2)
Up to 4 shelves per rack 8 Ru high per shelf unit Horizontal mount in a 23 in. rack with 21.5 in.
opening
7360 ISAM FX-8 Up to 4 shelves per rack 8 Ru high per shelf unit Horizontal mount in a 19 in. rack with 17.75 in.
opening
7360 ISAM FX-4
(3)
Up to 2 shelves per rack 16 Ru high per shelf unit Vertical mount in an EIA standard 19 in. rack with
17.75 in. opening
Vertical mount in a seismic rack with 17.5 in.
opening
Vertical mount in a 23 in. rack with 21.5 in.
opening
7360 ISAM FX-4
(2)
Up to 7 shelves per rack 5 Ru high per shelf unit Horizontal mount in a 23 in. rack with 21.5 in.
opening
7360 ISAM FX-4 Up to 7 shelves per rack 5 Ru high per shelf unit Horizontal mount in a 19 in. rack with 17.75 in.
opening
