Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Installing cards in the 7360 ISAM FX-16 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 125
DRAFT
7 Installing cards in the
7360 ISAM FX-16 shelf
7.1 Overview
7.2 Shelf areas and slot positions
7.3 Dummy front panels
7.4 Recommended tools
7.5 Guideline for card installation
7.6 Installation procedures
7.1 Overview
This chapter provides the procedures to install field-replaceable units (FRUs) in the
7360 ISAM FX-16.
7.2 Shelf areas and slot positions
Figure 52 shows the NT and LT slot positions in a 7360 ISAM FX-16 shelf.
Note — For an overview of the supported cards, see the
7360 ISAM FX Product Information Guide.
