Nokia 7360 Intelligent Services Access Manager FX Series User Manual

7360 ISAM FX-12 shelf cabling
186
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Figure 90 MDF cable POTS connection on 7360 ISAM FX-12
5 Secure the connector with baillocks.
6 Route and connect the other end of the MDF cable as per site practices.
7 STOP. This procedure is complete.
10.12 Vectoring cable connector
This DLP provides the steps to connect vectoring links between a NDPS-B card and
NDLS-E cards.
24948
GF C LT1 LT2 LT 3 LT4 LT6 NTA NTB NTIO LT5 LT7 LT8 LT9 LT10 LT12LT11
Alarm
ENERGY HAZARD
ROATING FAN BLADES
KEEP FINGERS AWAY FROM
TOP AND BOTTOM OF FAN TRAY
xDSL
PWR
ALM
MAJ
POTS LINE
PWR
ALM
