Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual 7360 ISAM WM shelf cabling
Issue: 09 3HH-12893-AAAA-TCZZA 415
DRAFT
Figure 241 Connecting the power cable
2 Tighten the nuts with a torque of 10 Nm (maximum 12 Nm).
22.6 Alarm cable
The 7360 ISAM WM external alarm cable has male and female DB50 connectors, as
well as a SUB-B 9-pin male connector. See Figure 242 for a view of the alarm cable.
25799
Energy Hazard
ALM
01 02 03 04 05 06 07 08 NTA NTIO NTB 09 10 11 12 13 14 15 16
BITS INTERFACE
TIME OF DAY
1 Hz-PULSE
NT-A NT-B
RING
TIP
FRAME GND
CO ALARMS
CRAFT PORT
TB1-2 BAT RTN A TB1
-
3 BAT R
T
N B
TB1-1 -
4
8V BAT A
TB1-4 -
48
V
BA
T B
CAUTION
ROTATING FAN BLADES
R
T
H
A
E
B
O
N
D
I
N
G
P
O
I
N
T
ESD
CRITICAL
MAJOR
MINOR
BAT A
BAT B
ACO
7360 ISAM FX-16
-48V 70A
Energy Hazard
Power Terminals
Power unit
of 7360 ISAM
FX-16 shelf
7360 ISAM FX-16
power cable lugs
7360 ISAM VM
equipment power
cable lugs
CAUTION: BEFORE REMOVING TERMINAL COVER,
DISCONNECT BOTH “A” AND “B” POWER SOURCES
CAUTION: TORQUE NUTS TO 65 IN-LBS MAX
