Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Installing racks
Issue: 09 3HH-12893-AAAA-TCZZA 69
DRAFT
6 Mount the connector plate to the top of the rack; see Figure 16.
Figure 16 Rack connector plate for 7-ft rack
Note — The connector adapter kit provides rack tie-down facilities per
Telecordia specifications.
22368
Adapter plate assembly kit
Flathead screw
Connector plate
Rack top
Hexhead screw
Hardware used for mounting
braces from connector plate
to overhead rails/cable tray
Lockwasher
