Nokia 7360 Intelligent Services Access Manager FX Series User Manual

7360 ISAM WM shelf cabling
414
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Procedure 94 Connecting the power cables
Proceed as follows to connect the 7360 ISAM WM power cable:
1 Connect the power cables to the 7360 ISAM FX-16; see routing from the 7360 ISAM WM in
Figure 240 and cable connection in Figure 241.
Figure 240 Routing the power cable
25794
ALM
PW2
S1
PW1
PW2
S2
RUN
PW1
FWPC-A
ALM
PW2
S1
PW1
PW2
S2
RUN
PW1
FWPC-A
