Nokia 7360 Intelligent Services Access Manager FX Series User Manual

Installing cards in the 7360 ISAM FX-16 shelf
130
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
7.6 Installation procedures
This section describes the following card installation procedures:
• To install NT cards
• To install NTIO cards
• To install LT cards
• To remove cards
7.6.1 General
When installing cards in a new installation, install the NT card(s) first. Allow the NT
cards to initialize and come in service before installing the LT cards. When replacing
an LT card, verify that the NT card is in service before inserting the LT card.
The NT and LT dummy panels (or filler plates) must be installed in any unused,
unpopulated NT or LT card slot in order to maintain proper operation. Filler plate units
have no electronic components; they are mechanical units used to provide ESD/EMI
seal and thermal seal in the 7360 ISAM FX-16.
Warning — Unplugging and reseating the active NT card in
less than 3 seconds may result in an approximately 1 minute
service interruption while the NT cards negotiate active/
standby state during initialization. Wait at least 5 seconds
before reseating an unplugged active NT card.
Note 1 — Redundant NT cards must be provisioned first before
they are installed. See the appropriate product Operations and
Maintenance Guide to configure an NT card and to configure
NT redundancy.
Note 2 — The following steps must be followed if the NTIO
board (FNIO-A) is moved to a new shelf:
• plan the NTIO board in the new shelf
• reset the shelf
• plug in the NTIO board
See Operations and Maintenance Guide for FD 100/320 Gbps
NT and FX NT for planning information.
