Installing racks
66
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
4.3.1 Parts list
General installation components include the following:
• 7360 ISAM FX supported rack
• 7360 ISAM WM supported rack
• adapter plate assembly kit; one required per rack (not included with rack; order
separately)
• concrete anchor setting tool; one required per installation site (not included with
rack; order separately)
Seismic installation components include the following:
• seismic rack extender; one optional per rack (not included with rack; order
separately). Order the height of seismic rack extender required to convert the 7-ft
rack to the height of the CO where the product is being installed. This component
extends the 7-ft rack, connecting to the CO overhead cable raceway rails only—
it does not allow additional shelf installation.
• seismic anchor bolt, size M12/25 (12 mm diameter bolt with 25 mm grip), four
required per rack (not included with rack; order separately)
• seismic anchor bolt, size M12/50 (12 mm diameter bolt with 50 mm grip), four
required per rack (not included with rack; order separately)
Non-seismic installation components include the following:
• floor mounting hardware kit; one kit required per rack (not included with rack;
order separately)
• anchor bolt, size M12/25 (12 mm diameter bolt with 25 mm grip), two or four
required per rack dependent on installation practice (not included with rack; order
separately)
4.3.2 Recommended tools
The following tools are recommended:
• extension cord, 50 ft (15 m)
• flathead and #2 Phillips screwdrivers
• handling materials, tools, method, and packing material for hazardous waste
material removal, if required
• level, 3 ft (1 m)
• rotary impact drill and associated drill bits
• safety glasses
Note — The standard anchor is M12/25. In applications where
the floor is not level and requires shimming greater than 0.125
in. (3.175 mm), the longer anchor (M12/50) may be required. In
all cases, make sure that the minimum embedment mark on the
anchor is at or below the level of the concrete.
