ANSI Hardware Installation Manual 7360 ISAM FX-8 shelf cabling
Issue: 09 3HH-12893-AAAA-TCZZA 263
DRAFT
14.4 Rack grounding connection
The 7360 ISAM FX-8 requires a 6 AWG rack frame grounding cable for the rack
grounding connection.
Procedure 55 To connect the rack ground
1 Prepare the frame grounding cable.
2 Following local practices, route the grounding cable to the top of the rack.
3 Connect the grounding cable to one of the two frame grounding points on the top of the rack,
as shown in Figure 137, using the screws provided with the rack.
Danger 1 — Rack or frame must be suitably connected to the
office grounding network in accordance with Article 250 of the
National Electrical Code (NEC) to ensure UL and CSA
compliance. If outside the United States, ground per local
electrical codes and practices.
Danger 2 — Possible risk of personal injury or damage to
equipment due to inaccurate or faulty ground cabling.
Inaccurate grounding connection can cause electric shock or
equipment damage when the rack power is switched on.
