Nokia 7360 Intelligent Services Access Manager FX Series - 16.2 Managing fiber optic cables

Fiber optic cable management in the
7360 ISAM FX-8 shelf
302
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Figure 166 Fiber management kit for 7360 ISAM FX-8
Figure 167 shows a view of the 7360 ISAM FX-8 heat and fiber baffle for vertical
mount configurations.
Figure 167 Baffle for 7360 ISAM FX-8 vertical rack mounting configurations
16.2 Managing fiber optic cables
This section describes how to fiber optic cables for NT cards and LT cards in the
7360 ISAM FX-8 shelf.
