Nokia 7360 Intelligent Services Access Manager FX Series User Manual

Installing a 7360 ISAM FX-8 shelf
240
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
13.3 Mounting the 7360 ISAM FX-8 shelf in a 23 in.
rack
The 7360 ISAM FX-8 shelf can be mounted:
• horizontally in a 23 in. rack with 21.5 in. opening
• vertically in a 23 in. rack with 21.5 in. opening
13.3.1 7360 ISAM FX-8 rack mounting configurations
Table 10 describes the horizontal rack mounting configuration for a 7360 ISAM FX-
8 shelf in a 23 in. rack. Figure 126 shows the horizontal rack mounting configuration.
Table 10 Horizontal mounting configuration supported in a 23 in. rack for
7360 ISAM FX-8
Caution — The vertical shelf mount kit must be used for the
7360 ISAM FX-8 in a vertical mount installation as the air intake
baffle/drip tray and top baffle are required to meet NEBS
preferred airflow specifications (air flows in the front, and out
the rear of the shelf).
Rack unit 23 in. rack horizontal mount
(21.5 in. opening)
SR 1 NFXS-E
Horizontal shelf mount kit
Fan 1 BFAN-E
(with fan filter)
SR 2 NFXS-E
Horizontal shelf mount kit
Fan 2 BFAN-E
(with fan filter)
