Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Installing cards in the 7360 ISAM FX-12 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 201
DRAFT
Figure 99 Location of earth bonding point
11.6.2.2 Cards with optical fiber connectors
Observe the following.
Figure 100 shows a laser classification label.
24899
GFC LT1 LT2 LT3 LT4 LT6 NTA NTB NTIO LT5 LT7 LT8 LT 9 LT1 0 LT1 2LT1 1
Alarm
ENERGY HAZARD
ROATING FAN BLADES
KEEP FINGERS AWAY FROM
TOP AND BOTTOM OF FAN TRAY
B: 60AA: 60A
External Alarms
BITS
NTA
GND
NTB
Remote
Craft
BAT A
BAT B
Min.
ACO
Maj. Crit.
Alarms
7360 ISAM FX-12
ESD
Danger — Risk of eye damage or skin burns by laser emission.
When installing optical cards or handling optical fibers, never
look inside connectors of cards or fibers when these are not
connected.
Put end caps on open connectors to protect against
unexpected emission.
Caution — Risk of damage by ESD when card is not
connected.
This card contains devices that are susceptible to damage
caused by ESD in unconnected circuit conditions.
Carefully follow ESD safety precautions.
