Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Connector pinning of the external interfaces
Issue: 09 3HH-12893-AAAA-TCZZA 447
DRAFT
Table 24 CO external alarm pinning for 7360 ISAM WM
Signal name Type Pin number Color Description
EXT_ALM_00 Input 1 White/tan External alarm input 1 (A terminal)
EXT_ALM_01 26 Tan/white External alarm input 1 (B terminal)
EXT_ALM_10 Input 2 White/brown External alarm input 2 (A terminal)
EXT_ALM_11 27 Brown/white External alarm input 2 (B terminal)
EXT_ALM_20 Input 3 White/pink External alarm input 3 (A terminal)
EXT_ALM_21 28 Pink/white External alarm input 3 (B terminal)
EXT_ALM_30 Input 4 White/orange External alarm input 4 (A terminal)
EXT_ALM_31 29 Orange/white External alarm input 4 (B terminal)
EXT_ALM_40 Input 5 White/yellow External alarm input 5 (A terminal)
EXT_ALM_41 30 Yellow/white External alarm input 5 (B terminal)
EXT_ALM_50 Input 6 White/green External alarm input 6 (A terminal)
EXT_ALM_51 31 Green/white External alarm input 6 (B terminal)
EXT_ALM_60 Input 7 White/blue External alarm input 7 (A terminal)
EXT_ALM_61 32 Blue/white External alarm input 7 (B terminal)
EXT_ALM_70 Input 8 White/violet External alarm input 8 (A terminal)
EXT_ALM_71 33 Violet/white External alarm input 8 (B terminal)
EXT_ALM_80 Input 9 White/gray External alarm input 9 (A terminal)
EXT_ALM_81 34 Gray/white External alarm input 9 (B terminal)
EXT_ALM_90 Input 10 Tan/brown External alarm input 10 (A terminal)
EXT_ALM_91 35 Brown/tan External alarm input 10 (B terminal)
EXT_ALM_100 Input 11 Tan/pink External alarm input 11 (A terminal)
EXT_ALM_101 36 Pink/tan External alarm input 11 (B terminal)
EXT_ALM_110 Input 12 Tan/orange External alarm input 12 (A terminal)
EXT_ALM_111 37 Orange/tan External alarm input 12 (B terminal)
EXT_ALM_120 Input 13 Tan/yellow External alarm input 13 (A terminal)
EXT_ALM_121 38 Yellow/tan External alarm input 13 (B terminal)
EXT_ALM_130 Input 14 Tan/green External alarm input 14 (A terminal)
EXT_ALM_131 39 Green/tan External alarm input 14 (B terminal)
EXT_ALM_140 Input 15 Tan/blue External alarm input 15 (A terminal)
EXT_ALM_141 40 Blue/tan External alarm input 15 (B terminal)
EXT_ALM_150 Input 16 Tan/violet External alarm input 16 (A terminal)
EXT_ALM_151 41 Violet/tan External alarm input 16 (B terminal)
(1 of 2)
