Installing cards in the 7360 ISAM FX-8 shelf
300
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Figure 165 Remove fixation screws for NGFC-H card
4 Remove the NGFC-H card from the shelf and wear the antistatic wrist strap. Place the card
in an ESD protective bag.
5 Remove the new NGFC-H card from its ESD protective bag. Wear the antistatic wrist strap.
6 Slide the new NGFC-H card in its slot.
7 Secure the NGFC-H card in place with the fixation screws. Maximum torque: 1 N.m ±10%.
8 Reconnect the power cable connectors and safety cover.
9 STOP. This procedure is complete.
