Nokia 7360 Intelligent Services Access Manager FX Series - Figure 7 Horizontal Mount Position for 7360 ISAM FX-4 in a 19 In. Rack

Overview
46
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Figure 7 Horizontal mount position for 7360 ISAM FX-4 in a 19 in. rack
22740
18.312
17.750
38 RU
5 RU
FAN
NTA NTIO NTB 01 02 03 04
7360 ISAM FX-4
TOD/IHZ
Critical Alarms
FUSE BAT A
Remote CraftBITSExternal Alarms
NTA GND NTB
Major
ACO
1
AB
2
3
Minor
BAT B
N594
7360 ISAM FX-4
