ANSI Hardware Installation Manual Overview
Issue: 09 3HH-12893-AAAA-TCZZA 51
DRAFT
For more information about the 7360 ISAM FX and 7360 ISAM WM, see the
following documents:
• For ordering information about the fan units, baffles, and mounting installation kits
required for each shelf, or any other equipment item, see the 7360 ISAM FX
Product Information Guide.
• For complete system description and unit descriptions (unit data sheets), see the
7360 ISAM FX System Description.
2.4 Initial site survey
Nokia recommends that a site survey be conducted prior to ordering installation
materials, to ensure a properly planned installation. During the site survey, at
minimum, the following items should be determined:
• equipment rack locations (floor plan)
• rack mounting requirements (anchoring from ceiling or floor)
• required lengths for:
• power cables from shelf to battery fused distribution panel (BFDP)
• optical fiber cables (length of NT cable runs)
• miscellaneous cables
• location of termination points and requirements for power and ground cables
between 7360 ISAM FX racks and battery distribution feed card (BFDP)
(customer provided).
• termination points and requirements for the 7360 ISAM FX rack connection to the
office grounding architecture
• distribution frame termination block requirements (if not customer provided)
• cable rack, auxiliary framing, and overhead-rack bracing requirements
• length of NT cable runs and termination points
• cable loading considerations
This information must be communicated to Nokia.
Danger — Risk of dangerous or harmful situation if
inappropriate materials are used.
This can cause death or serious physical harm to persons or
damage to equipment.
The central office (CO) power cables, BAT A/B, battery return
(BATRET), and frame ground (FG) must be constructed from
the appropriate materials and must meet or exceed the
standard CO specification.
