Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Installing a 7360 ISAM FX-4 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 313
DRAFT
17.2.1 7360 ISAM FX-4 rack mounting configurations
Table 12 describes the horizontal rack mounting configurations for a 7360 ISAM FX-
4 shelf in an EIA standard 19 in. rack.
Table 12 Horizontal mounting configurations for 7360 ISAM FX-4 in a 19
in. rack
Note
(1)
Although only two 7360 ISAM FX-4 shelves are portrayed in this table, up to seven shelves in a rack is
supported.
Figure 172 shows the EIA standard 19 in. rack horizontal mounting configuration for
7360 ISAM FX-4.
Rack unit
(1)
EIA standard 19 in. rack (17.75 in.)
SR 1 NFXS-F
Horizontal shelf mount kit
Fan 1 BFAN-X
(with fan filter)
SR 2 NFXS-F
Horizontal shelf mount kit
Fan 2 BFAN-X
(with fan filter)
