Nokia 7360 Intelligent Services Access Manager FX Series User Manual

Installing cards in the 7360 ISAM FX-12 shelf
194
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Figure 94 LT and NT slot positions on 7360 ISAM FX-12
The 7360 ISAM FX-12 can be equipped with a maximum of 12 LT cards, 2 NT cards,
and 1 NTIO card.
11.3 Dummy front panels
Dummy front panels must be installed in any unused slot of a shelf to:
• ensure EMC compliance
• ensure thermal compliance through correct airflow in the shelf
• ensure safety by avoiding direct contact with backplane connectors
At slot deployment, the dummy front panel is replaced by the appropriate card and
the optical cables are connected to the card.
For more information on specific dummy front panels, see the 7360 ISAM FX Product
Information Guide.
11.3.1 NT dummy front panel
A dummy front panel must be used when the second NT card is not installed.
Figure 95 shows the dummy front panel for NT card slots.
LT
12
LT
11
LT
10
LT
9
LT
8
LT
7
NT
B
NT-
IO
NT
A
LT
6
LT
5
LT
4
LT
3
LT
2
LT
1
NGFC-I
Fan unit
24885
