ANSI Hardware Installation Manual Installing a 7360 ISAM FX-16 shelf

Issue: 09 3HH-12893-AAAA-TCZZA 85

DRAFT

Figure 24 Mounting 7360 ISAM FX-16 upper shelf in a 23 in. rack

9 STOP. This procedure is complete.

Note 1 — See Procedure 12 “To install a 7360 ISAM FX-16 heat and

fiber baffle kit above a shelf”.

Note 2 — See Chapter 6 “7360 ISAM FX-16 shelf cabling” for

7360 ISAM FX-16 shelf cabling information.

23915
