Installing a 7360 ISAM FX-16 shelf
84
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
8 Mount the shelf in the second upper mounting position in the rack by lifting the shelf over the
installed drip tray and then lowering it slowly into the correct mounting position. Attach the
shelf using the ten 12 × 24 1/2 in. (12 mm) hex screws provided in the bag labeled ‘Use these
screws to mount shelf to equipment rack’.
Figure 24 shows the previously installed bottom drip tray, and then the mounting of a
7360 ISAM FX-16 shelf in a 23 in. rack.
Danger — Risk of physical harm or damage when lifting shelf.
The shelf must be lifted by two persons. Pay attention to possible sharp
edges, when handling. It is advisable to wear protective gloves.
To Next Page
