ANSI Hardware Installation Manual Connector pinning on NT card

Issue: 09 3HH-12893-AAAA-TCZZA 455

DRAFT

Table 30 Local craft interface signal list and pinning

Signal name Description Type Pin

number

DB9 (female)

number

Signal

name

LCMI_RI_DSR Local-craft-mgt-itf “data-set-ready” Output 1 6 DSR

9RI

LCMI_DCD Local-craft-mgt-itf “data-carrier-detect” Output 2 1 CD

LCMI_DTR Local-craft-mgt-itf “data-terminal-ready” Input 3 4 DTR

EG Electrical ground or “signal ground” REF 4 5 GND

LCMI_RXD Local-craft-mgt-itf related serial receive-data Output 5 2 RXD

LCMI_TXD Local-craft-mgt-itf related serial transmit-data Input 6 3 TXD

LCMI_CTS Local-craft-mgt-itf “clear-to-send” Output 7 8 CTS

LCMI_RTS Local-craft-mgt-itf “request-to-send” Input 8 7 RTS
