Nokia 7360 Intelligent Services Access Manager FX Series User Manual

Installing cards in the 7360 ISAM FX-12 shelf
196
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Figure 96 Universal dummy front panel for NTIO card
11.3.3 Dummy front panel for optical LT cards
A dummy front panel must be used for all unused LT card slots. Figure 97 shows one
example of a dummy front panel for optical LT card slots.
Figure 97 Dummy front panel for optical LT card
Note — This dummy front panel can also be used for LT slots
where no pre-cabling is foreseen.
22429
26133
X
XXX
X
X
X
X
X
XX
xx
