Installing cards in the 7360 ISAM WM shelf
422
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
23.5 Guideline for card installation
This section provides a general guideline for the correct installation of a card in a
shelf.
Procedure 95 Installing a card
To install a card:
1 Gently plug the card in the shelf until the front panel of the board touches the shelf. Guide the
card to the right of the slot in the shelf card guides, while taking care that the SMD
components of the card do not touch the card mounted below.
2 Pull back the ejector handles.
3 Place on thumb at the left on the front panel next to the mnemonic label and place the other
thumb on the front panel below the top ejector handle.
4 Push with the lower thumb and guide with the top thumb, which should cause the ejector
handles to move in.
5 Push both ejector handles simultaneously to completely insert the card in the shelf slot.
6 Lock the card in place by fastening the fixation screws.
23.6 Installation procedures
This section describes the following card installation procedures:
• To install power cards
• To install controller cards
• To install line cards
• To remove cards
