Installing a 7360 ISAM FX-8 shelf

252

ANSI Hardware Installation Manual

3HH-12893-AAAA-TCZZA Issue: 09

DRAFT

Figure 134 Mounting the 7360 ISAM FX-8 shelf assembly vertically in a 23 in.

rack

10 STOP. This procedure is complete.

13.4 Installing or replacing a fan unit in a

7360 ISAM FX-8 shelf

The fan unit is a field-replaceable unit with wide-voltage-range fans and an alarm

interface board and (optional) fan filter. The unit is installed in the shelf fan area and

plugs directly into the backplane connectors. The front panel includes a single red

alarm LED that lights up if fan failure occurs.

Note — See Chapter 14 “7360 ISAM FX-8 shelf cabling” for

7360 ISAM FX-8 shelf cabling information.
