Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Installing cards in the 7360 ISAM FX-8 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 283
DRAFT
15 Installing cards in the
7360 ISAM FX-8 shelf
15.1 Overview
15.2 Shelf areas and slot positions
15.3 Dummy front panels
15.4 Recommended tools
15.5 Guideline for card installation
15.6 Installation procedures
15.1 Overview
This chapter provides the procedures to install field-replaceable units (FRUs) in a
7360 ISAM FX-8 shelf.
15.2 Shelf areas and slot positions
Figure 151 shows the LT and NT card slot positions in a 7360 ISAM FX-8 shelf.
Note — For an overview of the supported cards, see the
7360 ISAM FX Product Information Guide.
