5.2 Mounting the 7360 ISAM FX-16 shelf in a 23 in.
rack
The 7360 ISAM FX-16 shelf can be mounted vertically in a standard 23 in. rack with
a 21.5 in. opening.
5.2.1 7360 ISAM FX-16 rack mounting configurations
Table 6 lists the rack mounting configurations with the 7360 ISAM FX-16 shelf.
Table 6 Rack mounting configurations for 7360 ISAM FX-16 shelf
Caution — Due to the high heat dissipation for the
7360 ISAM FX-16, special equipment room cooling may be
required, or aisle spacing may need to be increased.
Caution — The 7360 ISAM FX-16 heat and fiber baffle kit and
drip tray must be used in a vertical mount installation to meet
NEBS preferred airflow specifications (air flows in the front, and
out the rear of the shelf).
Rack unit FEMA code
3FE 66742 AA 3FE 66742 AB
SR 1 NFXS-D NFXS-D
Heat and fiber baffle kit Heat and fiber baffle kit
Drip tray Drip tray
Fan 1 BFAN-H
(with fan filter)
BFAN-H
(with fan filter)
SR 2 — NFXS-D
— Heat and fiber baffle kit
— Drip tray
Fan 2 — BFAN-H
(with fan filter)
