Nokia 7360 Intelligent Services Access Manager FX Series User Manual

Connector pinning of the external interfaces
446
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Table 24 describes the CO external alarm pinning for the 7360 ISAM WM shelf.
VIS_CRI_A Output 21 Brown/green Critical alarm external visual indicator
(relay Contact A)
VIS_CRI_B 46 Green/brown Critical alarm external visual indicator
(relay Contact B)
AUD_MIN_A Output 22 Brown/blue Minor alarm external audible indicator
(relay Contact A)
AUD_MIN_B 47 Blue/brown Minor alarm external audible indicator
(relay Contact B)
AUD_MAJ_A Output 23 Brown/violet Major alarm external audible indicator
(relay Contact A)
AUD_MAJ_B 48 Violet/brown Major alarm external audible indicator
(relay Contact B)
AUD_CRI_A Output 24 Brown/gray Critical alarm external audible indicator
(relay Contact A)
AUD_CRI_B 49 Gray/brown Critical alarm external audible indicator
(relay Contact B)
Not connected — 25 — No contact
Not connected — 50 — No contact
Signal name Type Pin number Color Description
(3 of 3)
