Nokia 7360 Intelligent Services Access Manager FX Series User Manual

ANSI Hardware Installation Manual Connector pinning of the external interfaces
Issue: 09 3HH-12893-AAAA-TCZZA 445
DRAFT
EXT_ALM0_40 Input 5 White/yellow External alarm input 5 (A terminal)
EXT_ALM0_41 30 Yellow/white External alarm input 5 (B terminal)
EXT_ALM0_50 Input 6 White/green External alarm input 6 (A terminal)
EXT_ALM0_51 31 Green/white External alarm input 6 (B terminal)
EXT_ALM0_60 Input 7 White/blue External alarm input 7 (A terminal)
EXT_ALM0_61 32 Blue/white External alarm input 7 (B terminal)
EXT_ALM0_70 Input 8 White/violet External alarm input 8 (A terminal)
EXT_ALM0_71 33 Violet/white External alarm input 8 (B terminal)
EXT_ALM0_80 Input 9 White/gray External alarm input 9 (A terminal)
EXT_ALM0_81 34 Gray/white External alarm input 9 (B terminal)
EXT_ALM0_90 Input 10 Tan/brown External alarm input 10 (A terminal)
EXT_ALM0_91 35 Brown/tan External alarm input 10 (B terminal)
EXT_ALM0_100 Input 11 Tan/pink External alarm input 11 (A terminal)
EXT_ALM0_101 36 Pink/tan External alarm input 11 (B terminal)
EXT_ALM0_110 Input 12 Tan/orange External alarm input 12 (A terminal)
EXT_ALM0_111 37 Orange/tan External alarm input 12 (B terminal)
EXT_ALM0_120 Input 13 Tan/yellow External alarm input 13 (A terminal)
EXT_ALM0_121 38 Yellow/tan External alarm input 13 (B terminal)
EXT_ALM0_130 Input 14 Tan/green External alarm input 14 (A terminal)
EXT_ALM0_131 39 Green/tan External alarm input 14 (B terminal)
EXT_ALM0_140 Input 15 Tan/blue External alarm input 15 (A terminal)
EXT_ALM0_141 40 Blue/tan External alarm input 15 (B terminal)
EXT_ALM0_150 Input 16 Tan/violet External alarm input 16 (A terminal)
EXT_ALM0_151 41 Violet/tan External alarm input 16 (B terminal)
EXT_ALM0_160 Input 17 Tan/gray External alarm input 17 (A terminal)
EXT_ALM0_161 42 Gray/tan External alarm input 17 (B terminal)
EXT_ACO_A Input 18 Brown/pink External ACO switch (A terminal)
EXT_ACO_B 43 Pink/brown External ACO switch (B terminal)
VIS_MIN_A Output 19 Brown/orange Minor alarm external visual indicator (relay
Contact A)
VIS_MIN_B 44 Orange/brown Minor alarm external visual indicator (relay
Contact B)
VIS_MAJ_A Output 20 Brown/yellow Major alarm external visual indicator (relay
Contact A)
VIS_MAJ_B 45 Yellow/brown Major alarm external visual indicator (relay
Contact B)
Signal name Type Pin number Color Description
(2 of 3)
