ANSI Hardware Installation Manual Installing a 7360 ISAM FX-8 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 229
DRAFT
Procedure 48 To mount the 7360 ISAM FX-8 shelf horizontally in a 19 in. rack
Use this procedure to mount a 7360 ISAM FX-8 shelf horizontally in a 19 in. EIA standard rack.
1 Unpack and visually inspect the shelf for physical damage.
2 If anything is missing or damaged, notify the transportation carrier and Nokia immediately.
Photograph all the damaged equipment. Keep all the inspection and packing documents as
a reference.
3 Put on the antistatic wrist strap and connect it to a grounding point.
4 Verify the 7360 ISAM FX-8 shelf mounting locations on the rack; see Figure 117.
5 Orient the 7360 ISAM FX-8 shelf horizontally with the fan unit located on the right side and
align the shelf unit with the left and right rack mounting holes.
6 Mount the 7360 ISAM FX-8 shelf with 12-24 × 1/2 in. (12.7 mm) screws to the left rack
mounting hole, then to the right rack mounting hole securely.
Warning — Possibility of equipment damage.
Do not install damaged equipment, as it can adversely affect other
equipment.
