Installing a 7360 ISAM WM shelf
400
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
Procedure 91 Installing a 7360 ISAM WM shelf in a 23 in. rack
Proceed as follows to install a 7360 ISAM WM shelf:
1 Unpack and visually inspect the shelf and mounting kit for physical damage.
2 If anything is missing or damaged, notify the transportation carrier and Nokia immediately.
Photograph any damaged equipment. Keep all the inspection and packing documents as a
reference.
3 Put on the antistatic wrist strap and connect it to a grounding point.
4 Verify the 7360 ISAM WM shelf mounting positions, as shown in Figure 232.
Warning — Possibility of equipment damage.
Do not install damaged equipment, as it can adversely affect other
equipment.
Note — Figure 232 shows the 7360 ISAM WM installed at the bottom of
a rack, and in conjunction with a 7360 ISAM FX-16 shelf. The
7360 ISAM WM can also be installed in a rack with a 7360 ISAM FX-8 or
7360 ISAM FX-4 shelf, with similar installation and distance between
shelves. Contact your Nokia representative for more information.
