Installing a 7360 ISAM WM shelf
402
ANSI Hardware Installation Manual
3HH-12893-AAAA-TCZZA Issue: 09
DRAFT
6 Ensure that the drip tray has been installed in the correct position beneath the
7360 ISAM WM shelf.
7 Mount the 7360 ISAM WM shelf in the third lowest mounting position in the rack by lifting the
shelf over the already installed drip tray, and then lowering it slowly into the correct mounting
position.
8 Attach the shelf to the rack using eight 12 x 24 1/2 in. (12 mm) hex screws; see Figure 233.
Note 1 — A drip tray must be installed in the rack before the
7360 ISAM WM shelf is installed. See Procedure 90 “To install a drip tray
below a 7360 ISAM WM shelf”.
Note 2 — Once the drip tray is installed, the 7360 ISAM WM shelf must
be lifted over the drip tray and then lowered into the correct mounting
position, to avoid interference between the 7360 ISAM WM shelf and drip
tray side walls.
Warning — Risk of physical harm or damage when lifting shelf.
The shelf has to be lifted by two persons. Pay attention to possible sharp
edges when handling. It is advisable to wear protective gloves.
