ANSI Hardware Installation Manual Installing a 7360 ISAM FX-16 shelf
Issue: 09 3HH-12893-AAAA-TCZZA 81
DRAFT
Procedure 10 To mount the 7360 ISAM FX-16 shelf vertically in a 23 in. rack
Use this procedure to mount a 7360 ISAM FX-16 shelf vertically in a 23 in. rack.
1 Unpack and visually inspect the shelf and shelf mount kits for physical damage.
2 If anything is missing or damaged, notify the transportation carrier and Nokia immediately.
Photograph all the damaged equipment. Keep all the inspection and packing documents as
a reference.
3 Put on the antistatic wrist strap and connect it to a grounding point.
4 Verify the 7360 ISAM FX-16 shelf mounting positions as shown in Figure 22.
Caution — The heat and fiber baffle kit, and the drip tray kit must be
used for 7360 ISAM FX-16 installation to meet preferred airflow
specifications.
Warning — Possibility of equipment damage.
Do not install damaged equipment, as it can adversely affect other
equipment.
